Kystar KSV8C 2-in-1 LED Display Video Controller

Overview Kystar KSV8c 2-in-1 Controller supports 3-channel digital signal input and features 8 network port outputs, with a maximum load capacity of 5.2 million pixels. Adopting a pure hardware FPGA architecture, it enables 365×24 hours of continuous operation, fully meeting the configuration requirements of large-screen control systems for small-pitch applications. Features Equipped with 8 network ports in a standalone unit, each supporting up to 65K pixels. The entire unit can load a maximum of 520K pixels, with a maximum resolution of 8180×4090 pixels. Supports multiple digital signal interfaces, including 1 HDMI 1.3, 1 DVI-D, and 1 HDMI 1.4 input. Enables three-screen display with arbitrary layout configuration. Supports flexible cable routing; network port load is not restricted by rectangular boundaries, significantly improving network port utilization. Outputs test patterns such as solid color, gradient, and scan line, facilitating on-site debugging and testing. EDID configuration management: Supports reading, modifying, and customizing EDID (Extended Display Identification Data). Features one-click black screen/freeze function for quick operation. Border removal/cropping: Eliminates black borders generated by front-end signals and allows arbitrary cropping of any signal source while maintaining full-screen display. Supports key lock to prevent accidental operations. The brightness and contrast of the overall output image can be adjusted quickly and in real time.
