DS-7732NI-M4 32-ch 1.5U 8...

Video and Audio Specifications IP Video Input: Channels: 32-ch Maximum Resolution: Up to 32 MP Note: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs. Bandwidth: Incoming: 320 Mbps Outgoing: 400 Mbps Video Output: HDMI 1 Output: Resolutions Supported: 8K (7680 × 4320)/30Hz 4K (3840 × 2160)/60Hz 4K (3840 × 2160)/30Hz 2K (2560 × 1440)/60Hz 1920 × 1080/60Hz Note: When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p. HDMI 2 Output: Resolutions Supported: 4K (3840 × 2160)/60Hz 4K (3840 × 2160)/30Hz 2K (2560 × 1440)/60Hz 1920 × 1080/60Hz VGA Output: Resolution: 1920 × 1080/60Hz Video Output Mode: HDMI1/VGA simultaneous output, HDMI2/VGA independent output CVBS Output: 1-ch, BNC (1.0 Vp-p, 75 Ω) Resolutions: PAL: 704 × 576, NTSC: 704 × 480 Audio Output: Audio Output: 1-ch, RCA (Linear, 1 KΩ) Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) Decoding: Decoding Formats: H.265 , H.265, H.264 , H.264 Recording Resolutions: 32 MP, 24 MP, 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF Synchronous Playback: 16-ch Decoding Capability: 2-ch@32 MP (30 fps) 2-ch@8 MP (30 fps) 10-ch@8 MP (30 fps) 20-ch@4 MP (30 fps) 40-ch@1080p (30 fps) Dual-Stream Recording: Supported Network Specifications Network Protocols: TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS, ONVIF (Version 2.2), OTAP Network Interface: 2 x RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces Camera Access Protocol: ONVIF (Version 2.5), RTSP RAID: RAID Type: N/A Auxiliary Interfaces eSATA Interface: 1 SATA Interfaces: 4 Capacity: Up to 16 TB for each disk Serial Interfaces: 2 x RS-485 (half-duplex), 1 x RS-232 Alarm In/Out: 16/9 USB Interface Ports: Front panel: 2 x USB 2.0 Rear panel: 1 x USB 3.0 Power Output Ctrl 12V: Controllable 12 VDC, 1 A power output for external alarm devices; the power turns on when the alarm output is triggered. Note: The Ctrl 12V power is controlled by alarm output 9. DC 12V: 12 VDC, 1 A power output General Specifications Power Supply: 100 to 240 VAC, 50 to 60 Hz Power Consumption: ≤ 15 W (without HDD) Operating Temperature: -10 °C to 55 °C (14 °F to 131 °F) Operating Humidity: 10% to 90% Chassis: 19-inch rack-mounted 1.5U chassis Dimensions: 445 × 400 × 75 mm (17.5\” × 15.7\” × 3.0\”) Weight: ≤ 5 kg (11 lb, without HDD) Certifications FCC: Part 15 Subpart B, ANSI C63.4-2014 CE: EN 55032:2015 A1:2020 EN IEC 61000-3-2:2019 A1:2021 EN 61000-3-3:2013 A1:2019 EN 50130-4:2011 A1:2014 EN 55035:2017 A11:2020
