0-10V Light Brightness Dimming Power Driver – 24W This is a constant voltage dimmer that can be used by any compatible 0-10v dimmer. It can be used with our 4″ smart dimmer to dim downlights, LED strips and spotlights. Specifications: Provides a constant voltage output through a single channel, with a maximum output of 3.1A. Offers support for a 3-in-1 dimming mode, which includes 0/1-10V active signal, adjustable resistance, and PWM signal. Compatible with a high input voltage range of 220VAC to 240VAC. Dimming capability ranges from 0% to 100%, ensuring smooth dimming without flickering. Functions at 100% output when no dimming signal is present, serving as a regular power supply. Equipped with over load protection, over voltage protection, short circuit protection, and over temperature protection features. Designed with an IP20 rating, making it suitable for indoor LED lighting applications. Output Channels 1 Voltage 24VDC Current 1A Power 24W Voltage Accuracy ±3% Input Voltage 220-240VAC Frequency 50/60HZ Efficiency >85 %@230VAC,full load PF >0.95@230VAC,full load THD <10 %@230VAC,full load Current 0.15A@230VAC Inrush Current Cold start,15A(twidth=40us measured at 50% Ipeak) @230VAC Protections Over Temperature Close the output，automatically restore the normal temperature Short Circuit Close output，recovers automatically after fault removed Over Load Close output，recovers automatically after fault removed Function Dimming Mode 1-10V active signal, adjustable resistance and PWM signal Others Dimension 150*43*29mm G.W. 150g IP rating IP20 Working Temperature -20 ℃ ~ 50℃ Relative Humidity 20~90% RH Please leave this field empty WANT MORE? SIGN UP TO RECEIVE THE LATEST BLOG POSTS, PRODUCTS, PLUS SOME EXCLUSIVE DISCOUNTS! We don’t spam! Read our privacy policy for more info. Check your inbox or spam folder to confirm your subscription.
