Key Specifications Zones: 1 to 16 zones for fire detection coverage Main Voltage: 220-230V AC, 50/60 Hz System Voltage: 24V DC Zone Voltage: 21V DC Sounder Alarm Output: 2 outputs, each at 400mA @ 24V DC Fault Relay Output: 1x relay (1A max) Fire Relay Output: 1x relay (1A max) Battery and Power Management Battery Capacity: Space for up to 2 x 7AH 12V rechargeable batteries Battery Charger Protection: Includes short circuit and thermal overcharge protection Zone Short Circuit Protection: Ensures integrity of detection line even if a detector is removed, with no need for active End of Line (EOL) devices Key Features Microprocessor-Based Detection: High reliability with detector removal line integrity Relay Outputs: Fire and fault changeover relay outputs for integration with other systems Isolate Facility for Each Zone: Allows individual zones to be isolated as needed Front Panel Indicators: Short circuit and earth fault indications displayed on the front panel Programmable Sounder Delay: Adjustable delay for external sounders (0-9 minutes in 1-minute increments) One-Person Test Mode: Simplifies testing for single-person operation Easy Installation: Designed with top, bottom, and rear cable entries for flexible setup IP Rating: IP43 for moderate protection against dust and water ingress Applications This 1 to 16 Zones Conventional Fire Alarm Control Panel is ideal for buildings where fire detection in multiple zones is critical. Its user-friendly features and safety protections make it suitable for use in a variety of environments, from office buildings to manufacturing facilities.
