Novastar JT50 Plus LED Screen Asynchronous Card Multimedia Player

OverviewThe JT50 Plus is a multimedia player launched by Novartis for LED full-color displays in the transportation sector. It integrates playback and transmission functions and can be widely used in highways, urban roads, and parking lots, such as tollbooth information screens, traffic guidance screens, and passenger information system displays. The JT50 Plus ensures playback security through multiple protection measures, including terminal authentication and playback verification.Input/Output* Maximum Capacity: 650,000 pixels * Maximum Width: 2048, Maximum Height: 2048 (Single Ethernet port capacity within 650,000 pixels). * 1 Gigabit Ethernet Port for LED Output * 1 Stereo Audio Output Interface * Fixed audio sampling rate of 48kHz. When using a Nova multifunction card for audio output, 48kHz audio sampling rate must be used.Control* 1 USB 2.0 (Type A) Interface * Supports firmware upgrades via USB flash drive. * 1 USB (Type B) Interface * Directly connect the host computer to the device for program publishing and display control. * 1 100Mbps Ethernet Port * Directly connect the host computer to the device, or connect the device to a LAN or public network for program publishing and display control. * 2 RS485 Interfaces * Connect to a brightness sensor or temperature and humidity sensor.Performance  Powerful Processing Performance − Quad-core A53 ARM processor, 1.4GHz clock speed. − Supports 4K video hardware decoding. − 2GB RAM. − 32GB internal storage.Features  Supports Dual WiFi Mode − Supports WiFi AP: User terminals can connect to the JT50 Plus’s built-in WiFi hotspot. The default SSID is “Model SN last 8 digits”, and the default password can be found on the device’s SSID label. − WiFi AP Sta Mode: Users can simultaneously connect to WiFi and create a wireless hotspot.  Time Management − Supports NTP time synchronization. − Supports GPS time synchronization (requires a specified 4G module). − Supports RF time synchronization (requires a specified RF module). • Supports connection to brightness or temperature/humidity sensors. • Supports 4G module. − The JT50 Plus does not come with a 4G module by default; users can purchase one separately if needed. − Network priority: Wired > WiFi > 4G. • Supports mainstream transportation platform protocols. One-click switching between transportation protocols saves time and effort. • Supports relays (maximum DC 30V, 3A).Download Specification: Novastar JT50 Plus LED Screen Asynchronous Card Multimedia Player Specification(Chinese)
