Uniview 16-Channel 2MP Hybrid XVR301-16F Model XVR301-16F Video/Audio Input Analog Video Input 16-ch, BNC IP Video Input 2-ch(only IP up to 18ch), each channel up to 8MP Supported Analog Camera Types Support AHD input: 1080P@30fps 720P@30fps Support TVI input: 1080P@30fps 720P@30fps Support CVI input: 1080P@30fps 720P@30fps Support CVBS input Audio Compression G.711U Video/Audio Output VGA Output 1920x1080p/60Hz, 1920x1080p/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz HDMI Output 1920x1080p/60Hz, 1920x1080p/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz Synchronous Playback HD:16-ch SD:16-ch Live view display HDMI/VGA: 1/4/6/8/9/16/25 Snapshot FTP/Schedule/Event Snapshot Schedule snapshot is not supported 16-ch snapshot, up to 704*576 resolution Network Incoming Bandwidth 24Mbps (Up to 56Mbps after all analog channel conversion) Outgoing Bandwidth 64Mbps Remote Users 128 Protocols TCP/IP, P2P, UPnP, NTP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP Browser IE(IE10/11) for Windows Firefox (version 52.0 and above) for Windows Chrome(version 45 and above) for Windows Edge(version 79 and above) for Windows Encoding Recording Resolution 1080P Lite/720P/D1 Recording Frame Rate Main stream Sub stream 1080P Lite@12fps D1@12fps 720P@15fps D1@15fps Audio Sample Rate 8KHz,16 bit per channel Audio Bit Rate 64Kbps per channel Decoding Capability Analog:16x 1080P Lite@12, 16x 720P@15 IP: 1 x 8MP@30, 2 x 4MP@30, 4 x 1080P@30, 8 x 720P@30,16 x D1@30 Hard Disk SATA 1 SATA interface Capacity Up to 6TB for each HDD Smart Alarm VCA Detection Ultra Motion Detection(UMD) for analog:8-ch VCA Search Behavior Search General Alarm General Alarm Motion detection Alert Alarm IP Conflict, Network Disconnected, Disk offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal External Interface Network Interface 1 RJ45 10M/100M self-adaptive Ethernet Interface USB Interface Rear panel: 2 x USB2.0 General Power Supply 12V DC Power Consumption: ≤ 10 W( without HDD ) Working Environment -10°C ~ 55°C ( 14°F ~ 131°F ), Humidity ≤ 90% RH(non-condensing) Dimensions(W×D×H) 253mm × 212mm × 42mm (10.0″ × 8.4″ × 1.7″) Weight ( without HDD ) ≤0.85 Kg ( 1.87lb ) Certification Certification UL/CE/FCC /RoHS /WEEE
