DS-2CD1043G0-I – 4M...

Camera Specifications Image Sensor Type: 1/3\” Progressive Scan CMOS Max. Resolution 2560 × 1440 Min. Illumination Color: 0.01 Lux @ (F2.0, AGC ON) B/W: 0 Lux with IR Shutter Time 1/3 s to 1/100,000 s Day & Night IR Cut Filter Angle Adjustment Pan: 0° to 360° Tilt: 0° to 180° Rotate: 0° to 360° Lens Specifications Lens Type Fixed focal length (2.8 mm and 4 mm optional) Focal Length & Field of View (FOV) 2.8 mm Horizontal FOV: 98.0° Vertical FOV: 53.1° Diagonal FOV: 114.7° 4 mm Horizontal FOV: 78.7° Vertical FOV: 43.1° Diagonal FOV: 92.3° Lens Mount M12 Iris Type Fixed Aperture F2.0 Illuminator Specifications Supplement Light Type IR Supplement Light Range Up to 30 m Smart Supplement Light Yes IR Wavelength 850 nm Video Specifications Main Stream 50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440) 30 fps (1920 × 1080, 1280 × 720) Sub-Stream 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360) Video Compression Main stream: H.265/H.264/H.264 /H.265 Sub-stream: H.265/H.264/MJPEG Video Bit Rate 32 Kbps to 8 Mbps H.264 Type Baseline Profile/Main Profile/High Profile H.265 Type Main Profile Region of Interest (ROI) 1 fixed region for main stream Audio Specifications Audio Compression UF: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC Audio Bit Rate UF: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC) Audio Sampling Rate UF: 8 kHz/16 kHz Environment Noise Filtering UF: Yes Network Specifications Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS Simultaneous Live View Up to 6 channels API Open Network Video Interface, ISAPI User/Host Up to 32 users (3 levels: administrator, operator, user) Client iVMS-4200, Hik-Connect Web Browser Support Plug-in required live view: IE 10 Plug-in free live view: Chrome 57.0 , Firefox 52.0 Local service: Chrome 57.0 , Firefox 52.0 Image Settings Image Settings Saturation, brightness, contrast, sharpness, AGC, white balance adjustable via client software or web browser Day/Night Switch Auto, Schedule, Day, Night Wide Dynamic Range (WDR) 120 dB Image Enhancement BLC, 3D DNR Interface Specifications Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port On-Board Storage Built-in memory card slot, supports microSD card (up to 256 GB) Built-in Microphone Yes Reset Key Yes Event Specifications Basic Event Motion detection, video tampering, exception Linkage Options Upload to FTP, notify surveillance center, send email UF also supports: upload to memory card, trigger recording, trigger capture General Specifications Power 12 VDC ± 25%, 0.4 A, max. 5 W (Ø5.5 mm coaxial power plug) PoE: IEEE 802.3af, Class 3 (36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W) Material Metal & Plastic Dimension 177.6 mm × 66.2 mm × 67.8 mm (7.0\” × 2.6\” × 2.7\”) Package Dimension 216 mm × 121 mm × 118 mm (8.5\” × 4.8\” × 4.6\”) Weight Approx. 270 g (0.6 lb.) With Package Weight: Approx. 490 g (1.1 lb.) Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F); Humidity 95% or less (non-condensing) Startup and Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F); Humidity 95% or less (non-condensing) General Function Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter Approval and Certification EMC FCC SDoC (47 CFR Part 15, Subpart B) CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 A1: 2014) RCM (AS/NZS CISPR 32: 2015) IC VoC (ICES-003: Issue 6, 2016) KC (KN 32: 2015, KN 35: 2015) Safety UL (UL 60950-1) CB (IEC 60950-1:2005 Am 1:2009 Am 2:2013, IEC 62368-1:2014) CE-LVD (EN 60950-1:2005 Am 1:2009 Am 2:2013, IEC 62368-1:2014) BIS (IS 13252(Part 1):2010 A1:2013 A2:2015) Environment CE-RoHS (2011/65/EU) WEEE (2012/19/EU) REACH (Regulation (EC) No 1907/2006) Protection IP67 (IEC 60529-2013)
